IXYS DSEI30-12A DIODE GEN PURP 1.2KV 26A TO247AD
IXYS DSEI30-12A DIODE GEN PURP 1.2KV 26A TO247AD
Description
IXYS DSEI30-12A DIODE GEN PURP 1.2KV 26A TO247AD,
Specifications
| Product Attribute | Attribute Value |
|---|---|
| Part Number | DSEI30-12A |
| Manufacturer | IXYS / Littelfuse |
| Voltage – Forward (Vf) (Max) @ If | 2.55 V @ 30 A |
| Voltage – DC Reverse (Vr) (Max) | 1200 V |
| Technology | Standard |
| Supplier Device Package | TO-247AD |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Series | – |
| Reverse Recovery Time (trr) | 60 ns |
| Package / Case | TO-247-2 |
| Package | Tube |
| Operating Temperature – Junction | -40°C ~ 150°C |
| Mounting Type | Through Hole |
| Current – Reverse Leakage @ Vr | 750 µA @ 1200 V |
| Current – Average Rectified (Io) | 26A |
| Capacitance @ Vr, F | – |
| Base Product Number | DSEI30 |
